Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable

Brand Name : Halogen Free Cable

Model Number : TH-890149

Certification : UL, CSA, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.15~0.55 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10,000,000 meters monthly

Delivery Time : 5~10 working days

Packaging Details : 915 meters per carton, subject to the customized dimensions of product.

Type : Customized Cable

Catalogue : LSZH Cable

Feature : Wear Resistant

Rated : 105C Degree, 300V

Jacket : LSZH Compound

Standard : 100% RoHS Compliant

Contact Now

Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable

Customized Cable is the most featured products of Tongheng business. Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable is created strictly following customers requirement. As the professional manufacturer, Tongheng staff engage to create customer the best quality cable. Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable is one of the excellent example. Its remarkable advantage is wear resistant and LSZH complied.

Here below is the product properties:

Feature: wear resistant and LSZH compliant

Conductor material: oxygen free copper wire strands.

Application: XLR microphone

Spec to be customized per customers request.

Product parameters:

LSZH Cable	Conductor Structure	Insulation Thickness	Nominal Diameter	Screened Coverage	Sheath Thickness	Overall Diameter	Current Capacity
LSZH Cable	AWG	mm	mm	%	mm	mm	A
2C	30	0.38	1.10	≥70	1.15	5.00	0.4
2C	28	0.38	1.20	≥70	1.15	5.30	0.6
2C	26	0.38	1.30	≥70	1.15	5.40	0.8
2C	24	0.38	1.40	≥70	1.15	5.70	1.5
2C	22	0.38	1.60	≥70	1.15	6.10	2.5
2C	20	0.38	1.80	≥70	1.15	6.50	6.0
2C	18	0.38	2.10	≥70	1.15	7.10	10.0
2C	16	0.38	2.40	≥70	1.15	7.70	19.0
3C	30	0.38	1.10	≥70	1.15	5.30	0.4
3C	28	0.38	1.20	≥70	1.15	5.50	0.6
3C	26	0.38	1.30	≥70	1.15	5.70	0.8
3C	24	0.38	1.40	≥70	1.15	5.90	1.5
3C	22	0.38	1.60	≥70	1.15	6.50	2.5
3C	20	0.38	1.80	≥70	1.15	6.80	6.0
3C	18	0.38	2.10	≥70	1.15	7.40	10.0
4C	30	0.38	1.10	≥70	1.15	5.50	0.4
4C	28	0.38	1.20	≥70	1.15	5.70	0.6
4C	26	0.38	1.30	≥70	1.15	6.00	0.8
4C	24	0.38	1.40	≥70	1.15	6.40	1.5
4C	22	0.38	1.60	≥70	1.15	7.70	2.5
4C	20	0.38	1.80	≥70	1.15	7.20	6.0
5C	30	0.38	1.10	≥70	1.15	5.70	0.4
5C	28	0.38	1.20	≥70	1.15	5.80	0.6
5C	26	0.38	1.30	≥70	1.15	6.00	0.8
5C	24	0.38	1.40	≥70	1.15	6.40	1.5
5C	22	0.38	1.60	≥70	1.15	7.00	2.5
6C	30	0.38	1.10	≥70	1.15	5.90	0.4
6C	28	0.38	1.20	≥70	1.15	6.30	0.6
6C	26	0.38	1.30	≥70	1.15	6.70	0.8
6C	24	0.38	1.40	≥70	1.15	7.00	1.5

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.

Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable

Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable

Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable

Wear Resistant LSZH Complied Unshield Custom Made XLR Microphone Cable Images
